MSA020 24vdc weatherproof occupancy sensor DALI Interface

  • MSA020 24vdc weatherproof occupancy sensor DALI Interface
  • MSA020 24vdc weatherproof occupancy sensor DALI Interface
  • MSA020 24vdc weatherproof occupancy sensor DALI Interface
  • MSA020 24vdc weatherproof occupancy sensor DALI Interface
  • MSA020 24vdc weatherproof occupancy sensor DALI Interface
Place of Origin China
Brand Name Merrytek
Certification CE
Model Number MSA020
Minimum Order Quantity 100pcs
Price Negotiation
Packaging Details Color box + flat card + outer box (K=A)
Delivery Time 1, Sample and small order: Within 5 working days after receiving your payment. 2, Bulk order: 3-4 weeks after receiving deposit.
Payment Terms T/T or Western Union or PayPal
Supply Ability 10,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Detecting Technology Movement / Minor Motion / Breathing / Daylight Harvesting Working Mode On-off
Rated Voltage DALI Bus Power Supply (9.5V-24V DC) Transmitting Power 0.5mW Max.
Load Capacity 64 LED Drivers Max
Highlight

MSA020 weatherproof occupancy sensor

,

MSA020 ceiling mounted vacancy sensor

,

24vdc weatherproof occupancy sensor
Leave a Message
Product Description

Occupancy Sensor of Breathing Dedetecting with DALI Interface MSA020





1. Adopt Merrytek patented Lifebeing detected technology, which can detect movement, slight motion and breathing.

2. Built-in DALI interface, can work with DALI1.0 &DALI2.0 drivers.

3. Support single, group and broadcast working mode.

4. Support multiple access, multi-point acquisition of sensor data, transmissing the datas via broadcast mode to realize trigger synchronization in multi-azimuth.

5. DALI-Bus control, up to 64pcs DALI drivers, max. 300m.

MSA020 24vdc weatherproof occupancy sensor DALI Interface 0

Rated Voltage DALI bus power supply (9.5V-24V DC)
Load capacity 64LED drivers Max
Detecting Technology Occupancy detecting
Working Mode On-off
Operating Frequency 5.8 GHz ±75 MHz, ISM band
Transmitting Power 0.5mW Max.
Communication Method Standard DALI protocol signal
Cut Size φ65-70mm
Operating Temperature -25~50℃
IP Rating IP20



MSA020 24vdc weatherproof occupancy sensor DALI Interface 1

MSA020 24vdc weatherproof occupancy sensor DALI Interface 2

MSA020 24vdc weatherproof occupancy sensor DALI Interface 3

MSA020 24vdc weatherproof occupancy sensor DALI Interface 4

MSA020 24vdc weatherproof occupancy sensor DALI Interface 5

MSA020 24vdc weatherproof occupancy sensor DALI Interface 6

MSA020 24vdc weatherproof occupancy sensor DALI Interface 7
