High Frequency Microwave Motion Sensor Dimmable Motion Sensor MC083V





Description

  • High installation for car parks, etc.
  • Work with 1-10V dimmable LED driver, easy to achieve 2-step or 3-step dimming function.
  • 5.8GHz high frequency microwave(C-Band license-free operation)
  • DIP setting allows the user easy to adjust sensor parameters.
  • Automatically detect the daylight and remain OFF even detect any movement when the natural light is sufficient.
  • Particularly good value for money which would cost down the whole project.
  • Getting different effect and requirements by selecting different detection area, hold time and daylight threshold set by the DIP switch.
  • IP Rating would be IP20 and 5 years of warranty.



Function:

1- ON-OFF function

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 0

2- step dimming function

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 1

3- step dimming function

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 2



Detection Patter:

Ceiling mounting

Ceiling mounted height: 3m

Sensitivity: 100%/75%/50%/10%

Ceiling mounted height: 9m

Sensitivity: 100%/75%/50%/10%

Ceiling mounted height: 15m(*)

Sensitivity: 100%/75%/50%

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 3

Normal moving (Speed:1m/s)

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 4

Normal moving (Speed:1m/s)

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 5

Normal moving (Speed:1m/s)

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 6

Slow moving (Speed 0.3m/s)

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 7

Slow moving (Speed 0.3m/s)

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 8

Slow moving (Speed 0.3m/s)

* Only 100%/75%/50% detection sensitivity is workable when installed at 15m mounting height. 10% sensitivity is not able to detect motion signal.



Wall mounting

Horizon mounted height: 2m

Sensitivity: 100%/75%/50%/10%

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 9

Normal moving (Speed:1m/s)

Dimmable Microwave Motion Sensor 5.8GHz High Frequency DIP Setting MC083V 10

Slow moving (Speed 0.3m/s)



Specifications:

Operating voltage

198-264V AC 50/60Hz

Rated load

800W (Inductive), 1000W (Resistive) @230V AC

HF system 5.8GHz±75MHz, ISM wave band

Stand-by Power

≤0.5W

Transmitting power

0.5mW Max.

Detection zone Max.(D x H) 6m x 15m
Motion detection 0.3~3m/s
Detection angle 150°(wall installation) 360°(ceiling installation)
IP rating IP20
Operation temperature

-25℃…+60℃

Hold time

5S/30S/90S/3min/20min/30min

Detection Area

100%/75%/50%/10%

Daylight sensor

2Lux/5Lux/10Lux/25Lux/50Lux/100Lux/Disable

Stand-by DIM Level

25%(2.2-2.5V)/35%(3.0-3.5V)/50%(5.0-5.5V)

Life time 50,000 hours
Guaranty 5 years





DIP Switch Setting

Detection Area

  1 2
ON ON 100%
ON - 75%
- ON 50%
- - 10%



Hold Time

  3 4 5
ON ON ON 5s
- ON ON 30s
ON - ON 90s
- - ON 3min
ON ON - 20min
VI - - - 30min





Stand-by Period

  6 7 8
ON ON ON 0s
- ON ON 5s
ON - ON 5min
- - ON 10min
ON ON - 30min
VI - ON - 60min
VII - - - +∞





Stand-by Dim Level

  1 2
ON ON 50%
ON - 35%
- - 25%



Daylight Sensor

  1 2 3 4 5 6
ON ON ON ON ON ON 2lux
- ON ON ON ON ON 5lux
ON - ON ON ON ON 15lux
ON ON - ON ON ON 25lux
ON ON ON - ON ON 50lux
VI ON ON ON ON - ON 100lux
VII ON ON ON ON ON - Disable*

* Disable means the daylight sensor does not work. The sensor will turn on light once motion is detected regardless of ambient light level.



Applications:

  1. Tri-proof Lamp Installation
  2. Corridor
  3. Stairwell
  4. corridor Applications,etc
