8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating

  • 8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating
  • 8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating
  • 8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating
  • 8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating
  • 8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating
Place of Origin China
Brand Name Merrytek
Certification CE
Model Number MSA059D IR
Minimum Order Quantity 100pcs
Price Negotiation
Packaging Details White box+ White box tags+ Clapboard+ Carton(K=A)
Delivery Time 1, Sample and small order: Within 5 working days after receiving your payment. 2, Bulk order: 3-4 weeks after receiving deposit.
Payment Terms T/T
Supply Ability 10,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Input Voltage DALI Bus Power Supply Working Current 20mA MAX.
Power Consumption ≤0.5W Function DALI2.0 Protocol
Detecting Area (radius) 4-5m Mounting Height 2-8m
Installation Flush-mounted/EU86 Box/ Surface Mounted Warranty 3 Years
Leave a Message
Product Description

8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating


1. Features
1) PIR motion detection
2) DALI2.0 output

3) Complaint with 101,103,303,304 DALI standard
4) Daylight sensor detection is available
5) Detection area, hold time can be set by remote control
6) Max detection range: 8-10m in diameter
7) 8m max mounting height: Warehouse, workshop, and lobby motion detection is highly recommended
8) Flush mounting, EU 86 box mounting and surface mounting are available


2. Parameters

Input/Output Input voltage 9.5-22.5V DC(DALI BUS power)
Working current 20mA max
Power consumption ≤0.5W @12/24V DC
Output signal DALI2.0
Sensor parameter Function PIR motion detection+ daylight sensor
Detection Area Remote setting: 100%/75%/50%/25%
Hold Time MH10 remote: 5s/30s/1min/3min/5min/10min/20min/30min
Daylight Sensor measurement 2-65000Lux
Radius detection range(based on 100% sensitivity) 4-5m@25℃ based on 6m mounting height
Remote control Available
Mounting height 2-8m, typical value:6m
Application environment Drill hole Φ65-70mm
Working temperature -25℃...+50℃(detection range might differ based on different temperature )
Storage temperature -40℃~+80℃
Warranty 3 years(available based on product quality problem)
Certificate Standard Certificate Compliant to CE
Environmental requirements Compliant to RoHS
IP rating IP20
“N/A” means not available



3. Dimension
Flush mounted:
8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating 0
Surface Mounted

8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating 1

4. Wiring Diagram

8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating 2
5. Detection radiation
8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating 3


6. Remote Control MH10
8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating 4
8. The 3 mounting method we are talking about

8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating 5
