10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights

  • 10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights
  • 10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights
  • 10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights
  • 10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights
  • 10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights
Place of Origin China
Brand Name Merrytek
Certification CE
Model Number MSA059D IR
Minimum Order Quantity 100pcs
Price Negotiation
Packaging Details White box+ White box tags+ Clapboard+ Carton(K=A)
Delivery Time 1, Sample and small order: Within 5 working days after receiving your payment. 2, Bulk order: 3-4 weeks after receiving deposit.
Payment Terms T/T
Supply Ability 10,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Input Voltage DALI Bus Power Supply Working Current 20mA MAX.
Power Consumption ≤0.5W Function DALI2.0 Protocol
Detecting Area (radius) 4-5m Mounting Height 2-10m
Installation Flush-mounted/EU86 Box/ Surface Mounted Warranty 3 Years
Highlight

8m Mounting Height pir movement detector

,

Daylight Sensor pir movement detector

,

IP54 Rating pir movement detector
Leave a Message
Product Description

8m mounting height DALI2 pir movement detector with daylight sensor and 3 mounting method IP54 rating


1. Features
1) PIR motion detection
2) DALI2.0 output

3) Complaint with 101,103,303,304 DALI standard
4) Daylight sensor detection is available
5) Detection area, hold time can be set by remote control
6) Max detection range: 8-10m in diameter
7) 8m max mounting height: Warehouse, workshop, and lobby motion detection is highly recommended
8) Flush mounting, EU 86 box mounting and surface mounting are available


2. Parameters

Input/Output Input voltage 9.5-22.5V DC(DALI BUS power)
Working current 20mA max
Power consumption ≤0.5W @12/24V DC
Output signal DALI2.0
Sensor parameter Function PIR motion detection+ daylight sensor
Detection Area Remote setting: 100%/75%/50%/25%
Hold Time MH10 remote: 5s/30s/1min/3min/5min/10min/20min/30min
Daylight Sensor measurement 2-65000Lux
Radius detection range(based on 100% sensitivity) 4-5m@25℃ based on 6m mounting height
Remote control Available
Mounting height 2-10m, typical value:8m
Application environment Drill hole Φ65-70mm
Working temperature -25℃...+50℃(detection range might differ based on different temperature )
Storage temperature -40℃~+80℃
Warranty 3 years(available based on product quality problem)
Certificate Standard Certificate Compliant to CE
Environmental requirements Compliant to RoHS
IP rating IP20
“N/A” means not available



3. Dimension
Flush mounted:
10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights 0
Surface Mounted

10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights 1

4. Wiring Diagram

10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights 2
5. Detection radiation
10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights 3


6. Remote Control MH10
10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights 4
8. The 3 mounting method we are talking about

10m Mounting Height DALI occupancy detector for surface mounting in large mounting heights 5
