Product Details
Input Voltage 220-240Vac, 50/60Hz Working Current 20mA MAX.
Power Consumption ≤0.5W Function DALI + PUSH + Casambi
Detecting Area (radius) 4-5m Mounting Height 2.5-10m
Installation Flush-mounted/86 Box/ Surface Mounted Cut Size Φ65-70mm
Leave a Message
Product Description

10m mounting height Casambi Wireless Detectors PIR sensor with DALI and PUSH dimming


1. Features
1) PIR motion detection

2) Connect to the Casambi BLE ecosystem
3) Accurate motion detection with one channel DALI output and Casambi communication
4) Daylight sensor detection available
5) Support one channel PUSH on/off and dimming control
6) 10m max mounting height
7) Flush mounting and surface mounting are available

8) 3-year warranty period


2. Parameters

Input/Output Input voltage 220-240V AC
Rated voltage 220V AC
Working current 20mA max
Power consumption ≤0.5W @220/230V AC
Output signal DALI+PUSH+casambi
Sensor parameter Function PIR motion detection +  daylight sensor
Detection Area Casambi app setting: 100%/75%/50%/25%
Sensor Hold Time Casambi app setting: 5S/1min/3Min/10Min
Daylight Sensor 0-1200lux
Radius detection range(based on 100% sensitivity and tangential moving) 4-5m@25℃ based on 6m mounting height(radial moving trigger range shall be less than tangential moving)
Remote control Available
Mounting height 2.5-10m, typical value: 8m
Application environment Drill hole Φ55mm
Working temperature -25℃...+50℃(detection range might differ based on different temperature)
Storage temperature -40℃~+80℃
Warranty 5 year(available based on product quality under indoor application)
Certificate Standard Certificate Compliant with CE
Environmental requirements Compliant with RoHS
IP rating IP20(flush mounting) IP54(surface mounting)
“N/A” means not available



3. Dimension

Flush mounted:

                        10m mounting height Casambi Wireless Detectors IR detector with DALI and PUSH dimming 0
Surface Mounted



10m mounting height Casambi Wireless Detectors IR detector with DALI and PUSH dimming 1

10m mounting height Casambi Wireless Detectors IR detector with DALI and PUSH dimming 2



4. Wiring Diagram

                            10m mounting height Casambi Wireless Detectors IR detector with DALI and PUSH dimming 3
5. Detection of radiation

10m mounting height Casambi Wireless Detectors IR detector with DALI and PUSH dimming 4



6. Casambi App setting (for reference only, for more information, please contact the sales representative)

10m mounting height Casambi Wireless Detectors IR detector with DALI and PUSH dimming 5



For more information, please get in touch with our sales rep. for more details.
