Detachable Microwave Motion Sensor MC015S-D Movement Detector On Off Control

Place of Origin China
Brand Name Merrytek
Certification CE & R&TTE
Model Number MC015S-D
Minimum Order Quantity Stop production, not available.
Price Negotiation
Packaging Details Packed in bubble bags firstly, and then reinforced with carton for outer packing
Delivery Time 1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Payment Terms T/T, Western Union
Supply Ability 20,000pcs per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
HF System 5.8GHz ±75MHz, ISM Wave Band Product Name Microwave Motion Sensor
Approval CE , R&TTE Operation Temperature -20℃~60℃
Rated Load 400W (inductive), 1000W (resistive) Function On-off Control
Operating Voltage 220-240Vac,50HZ IP Rating IP 20
Detection Max(D×H):12m×6m
High Light

Movement Detector RC Motion Sensors

,

400W Microwave Motion Sensor Switch

,

Detachable Microwave Motion Sensor

Leave a Message
Product Description

Stop production, not available.



Detachable Microwave Motion Sensor MC015S-D / Movement Detector On-off Control With CE 5 Years Warranty





Description:

MC015S-D is an innovative and active motion detector with HF system 5.8GHz. It automatically switches on/off light based on motion and ambient light level. Can control all kinds of lamps, for example, halogen, fluorescent and LED lights. Compact size and small casing, suitable to fix within most luminaires . Motion can be detected through plastic, glass and thin non-metal materials.



1. Automatic switching based on motion and ambient light level.

2. Compact size makes it suitable to fix within most luminaires.

3.  4-pole press-in terminal (L, N, N,L′),easy assembly

4. Zero-crossing point operation helps protect the sensor against in-rush current..

5. 5.8GHz high frequency microwave(C-Band license-free operation)

6. Detection area, time delay and daylight threshold can be precisely set via DIP switch.

7. MC015S-D is an innovative and active motion detector with HF system 5.8GHz. It automatically switches on/off light based on motion and ambient light level. Can control all kinds of lamps, for example, halogen, fluorescent and LED lights. Compact size and small casing, suitable to fix within most luminaires . Motion can be detected through plastic, glass and thin non-metal materials.



Function:

ON-OFF function

Detachable Microwave Motion Sensor MC015S-D Movement Detector On Off Control 0

Wiring :



Detachable Microwave Motion Sensor MC015S-D Movement Detector On Off Control 1

Detection Patter:

Detachable Microwave Motion Sensor MC015S-D Movement Detector On Off Control 2



Specifications:

Operating voltage

220-240Vac, 50Hz

Rated load

Inductive :400W,Resistive : 800W

HF system

5.8GHz±75MHz, ISM wave band

Power consumption

≤0.5W(standby), <1W(operation)

Transmitting power

<0.5mW

Detection zone Max.(D x H)

12m x 6m

Motion detection

0.5~3m/s

Detection angle

150°(wall installation) 360°(ceiling installation)

IP rating

IP20

Operation temperature

-20℃~60℃

Hold time

10s / 30s / 90s / 3min / 20min / 30min

Detection sensitivity

10% / 25% / 50% / 75% / 100%

Daylight sensor

5lux / 10lux / 30lux / 50lux / Disable

Life time

50,000 hours

Guaranty

5 years







Detachable Microwave Motion Sensor MC015S-D Movement Detector On Off Control 3

Applications:

Stairwell, Corridor,Balcony, Pathway, etc
