Plastic Outdoor Wireless Motion Sensor / Motion Detector For Street Light

Place of Origin China
Brand Name Merrytek
Certification CE , R&TTE
Model Number MC012V
Minimum Order Quantity Stop production, not available.
Price Negotiation
Packaging Details Packed in bubble bags firstly, and then reinforced with carton for outer packing
Delivery Time 1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Payment Terms T/T, Western Union
Supply Ability 20,000pcs per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Application Street Light Rated Load 800w(Inductive) 1200w(Resistive)
Operating Voltage 120-240VAC,50/60Hz Detection Max (25*20m)
HF System 5.8GHz ±75MHz, ISM Wave Band Size (L×W×H) 121x75x 30.5mm
Approval CE & R&TTE Operation Temperature -35℃~70℃
Dimming Mode RF Wireless Networking , 3 Step Dimming IP Rating IP20
High Light

dimming motion sensor


outdoor motion sensor


Plastic Outdoor Wireless Motion Sensor

Leave a Message
Product Description


Plastic 5.8GHz Wireless Motion Sensor / Motion Detector For Street Light




  •   Special narrow & long detection area (10m x 25m).
  •   With higher mounting height, up to 20m.
  •   It is suitable for street light application .
  •   Used in wireless networking of luminaries, easy installation and free of wire.
  •   With fixed code, very easy to step up any-to-any communication.
  •   By digital receiving and transmitting method, high anti-interference capability and no interference to an RF sensitive device, for example, electronic keys of cars.
  •   With advanced code detection technology, no code missing.
  •   Merrytek takes the lead in using the rotary coding switch in RF transceiver, very easy to create groups.
  •   MC012V is an active motion detector with HF system 5.8GHz. Motion can be detected through plastic, glass and thin non-metal materials.
  •   The RF module integrates advanced code check technology, significantly improved transmission reliability. Make sure exact signal transmitting and receiving, no code missing.
  •   Merrytek takes the lead in adopting the rotary coding switch to set up groups, very simple to achieve any-to-any communication.







Operating voltage

120-240Vac, 50/60Hz

Rated load

800W (inductive), 1200W(resistive)

HF system

5.8GHz±75MHz, ISM wave band

Power consumption

≤0.5W(standby), <1W(operation)

Transmitting power


Detection zone Max.(D x H)

Max (25*20m)

Motion detection


Detection angle

150°(wall installation) 360°(ceiling installation)

IP rating


Operation Temperature


Hold time


Detection sensitivity


Daylight sensor

5lux / 10lux / 30lux / 50lux / Disable

Stand-by dimming level


Stand-by period


Masking time

10s /1h /2h /4h / 6h/ 8h

Life time

50,000 hours


5 years






This product with narrow & long detection area (10m x 25m). Which is suitable for Street light application .
